Subsurface Utility Locating

The Zachman Group offers subsurface utility locating services utilizing Ground Penetrating Radar (GPR) and Electromagnetic Detection (EM). Subsurface utility locating is highly important for soil boring, excavation, directional boring, day-lighting, As-Built confirmation, and retrofit design.

Subsurface Utilities To Consider Prior To The Start of Your Project: Electrical, Gas, Communications, Sanitary Sewer, Storm Drains, Steam, Potable Water, Fire Services, and Irrigation.

Diagram of a subsurface utility locating workflow.

FAQ

Frequently Asked Questions
Ground Penetrating Radar (GPR) often referred to as Concrete Scanning or Concrete X-ray, works by sending a pulse of energy into concrete and measuring the strength and time of the returning signal. The equipment will repeat this action multiple times as the unit is maneuvered across a surface and process the returning data points. This processed data will then appear on the operating system's monitor and is interpreted by the GPR Operator.
